SLKN 01

Нержавеющий дренажный канал для бассейна, длина 2 м, AISI 304

Характеристики

CHANNEL

  • material CrNi 18/10 (AISI -304) or CrNi 17/12 (AISI-316L), thickness 1,2 mm
  • length 2000, 4000 mm; different lengths could be made to order
  • ruff around the channel for connection to hydro-isolation
  • mounting legs with M10 screws for better seating of the channel to the floor (horizontal position)
  • bond screw for connection with bonding conductor
  • gradient of the channel: 1 cm on 1 m

WASTE OUTLET

  • Ø 50 mm, rate of flow 20 l/min (atypical dimensions could be made to order)
  • easy to clean, with a stink trap
  • max. one water outlet in 4 meters long channel

GRID

  • material CrNi 18/10 (AISI -304) or CrNi 17/12 (AISI-316L), thickness 1,2 mm
  • brushed finish (polished finish for additional charge)
  • dimensions of the hole 5 x 50 mm (width x length)
  • safe for children



Арт. № 69010
Название SLKN 01

Спецификация поставки

SLKN 01 - supply No. 69010 - AISI-304 stainless steel slotted drain (2 m); stainless steel waste outlet with a stink trap, grid
